Premium Kingsman 36" Zero Clearance Direct Vent Gas Fireplace - HBZDV3628

Experience the pinnacle of Zero Clearance Direct Vent Fireplaces for your new home or renovation project. This is the perfect solution for installation in any room of your house. Experience the ultimate in safety and design with Kingsman fireplaces. This 36-inch gas-burning masterpiece boasts premium materials, a dual burner, wall switch, 4/7" sloped top flute, tempered glass, and louvered framing. And the best part? It features a completely sealed combustion unit and top-of-the-line silicone paint for a flawless finish. Discover the magic of dancing flames and glowing embers with Kingsman quality fireplaces, available in both natural gas and liquid propane. Achieve up to 85% maximum efficiency while creating an elegant and warm focal point in your home. With fully sealed combustion chambers, Kingsman fireplaces ensure no pollution spillage and maintain the indoor air quality of your home.

Features

• Millivolt or IPI valve system allows operation during a power failure with Hi/low heat and flame adjustment
• Dual burner with Realistic Flame Pattern
• A flame sensor that constantly monitors the pilot flame and provides 100% gas shut off if pilot is not sensed
• Safety Screen Barrier

Model	HBZDV3628N/NE	HBZDV3628LP/LPE
Fuel	Natural	Propane
Flue	Top	Top
Gas Control	Millivolt / IPI	Millivolt / IPI
Input Max.	28,000 BTU	26,000 BTU
Input Min.	20,000 BTU	19,000 BTU
FE (p.4.1-02)%	60.61% / 62.69%	62.48% / 64.16%
Venting	4/7" Flex or 4/6 5/8" Hard Pipe	4/7" Flex or 4/6 5/8" Hard Pipe
Viewing Area	29 3/4" W x 18 5/8" H	29 3/4" W x 18 5/8" H
Glass Type	Ceramic	Ceramic
Certification	Heater	Heater
Actual Width	38 1/16"	38 1/16"
Actual Height	34 11/16"	34 11/16"
Actual Depth	18 7/8"	18 7/8"
Actual Width	36"	36"
Actual Height	34 13/16"	34 13/16"
Actual Depth	16 7/16"	16 7/16"
Power Vent	Yes	Yes



Downloads

• Brochures
• Kingsman Collection
• Manual

Now available with enhanced quality and crafted for lasting performance.
